RDP-J216
NVIDIA Jetson Orin Nano 1U server — 20/40 TOPS, 5× M12 Gigabit, for rail foreign-object detection
Application Scenarios
- Security Surveillance
- Smart Manufacturing
- Rail Transit
- Smart City
- Smart Transportation
Key Features
- 20/40 TOPS compute in a standard 1U chassis (200mm depth)
- 5× M12 Gigabit Ethernet ports with dedicated IP
- Rail track scanning via multi-sensor fusion for foreign-object detection
- Mass storage: SSD plus 2.5"/3.5" SATA HDDs (optional)
- Active cooling with aviation-standard connectors
- Reduces collision risk and false braking alarms
Product SKU
| Model | RDP-J216 |
|---|---|
| AI Platform | NVIDIA Jetson Orin Nano |
| Form Factor | 1U Rack Edge AI · 483 × 205 × 44.4mm |
| Origin | Designed and manufactured in India by RDP Technologies Limited, Hyderabad |
AI Compute
| AI Computing Power | 20 / 40 TOPS (Super Mode: 34 / 67 TOPS) |
|---|---|
| GPU | 512-core (16 Tensor Cores) / 1024-core (32 Tensor Cores) NVIDIA Ampere architecture GPU |
| CPU | 6-core Arm® Cortex®-A78AE v8.2 64-bit CPU |
Memory & Storage
| Memory | 4GB 64-bit / 8GB 128-bit LPDDR5 |
|---|---|
| Storage | Supports external NVMe |
| Expansion (M.2 Key M) | 1× 2280 PCIe SSD · 2× SATA3 HDD (1×3.5" or 2×2.5") (optional) |
Video
| Video Encoding | 1080p30 supported by 1–2 CPU cores |
|---|---|
| Video Decoding | Up to 1× 4K60 · 2× 4K30 · 5× 1080p60 · 11× 1080p30 (H.265) |
Networking & Wireless
| Ethernet | 5× M12 Gigabit Ethernet ports, dedicated IP |
|---|
I/O & Interfaces
| Display | 1× HDMI |
|---|---|
| USB | 2× USB 3.0 Type-A · 1× Type-C USB2.0 · 1× Type-C debug |
Power & Electrical
| Power Input | DC110V, interface type M12 4X Acode |
|---|---|
| Power Interface | M12 4X Acode |
| Buttons / Indicators | Recover / Rst (2 buttons) · 2 indicator lights |
Physical & Environment
| Dimensions | 483 × 205 × 44.4mm |
|---|---|
| Operating Temperature | −20–60°C |
| Operating Humidity | 5%–95% non-condensing |
| Cooling | Fan cooling |
Compliance & Warranty
| Software | Ubuntu 20.04 · NVIDIA JetPack SDK (pre-installed) |
|---|---|
| Compliance & Certifications | BIS · CE · FCC · RoHS · ISO 9001 · MeitY Recognised · PLI 2.0 · GeM Listed |
| Warranty | 3 years parts · 3 years labor · 1 year cross-ship (3/3/1 standard) |
| Support | PAN-India SLA-backed service network across 300+ PIN codes |
